| Specification | Description |
|---|---|
| Maximum Grinding | 24" X 12" |
| Max Longitudinal Travel | 29.5" |
| Max Cross Travel | 13.4" |
| Max Vertical Clearance (12" Wheel) | 13.7" |
| Max Workpiece Weight | 924 Lbs. |
| Motor Speed (60 Hz) | 1,800 RPM |
| Spindle Motor | 4.8 HP |
| Longitudinal Feed | |
| Hydraulic Feed | 11.8 - 984.3 in/min |
| Hand Feed per Revolution | 1.9" |
| Cross Movement of Saddle | |
| Hydraulic Intermittent Feed | 0.02" - 0.79" |
| Hydraulic Continuous Feed | 0 - 39.4 in/min |
| Hand Feed per Revolution | 0.2" |
| Graduation of Handwheel | 0.0008" |
| Vertical Movement of Hand Wheel Head | |
| Auto Feed Down Feed (12 Steps Rough) | 0.00005 - 0.0015" |
| Auto Feed Down Feed (11 Steps Fine) | 0.00005 - 0.0005" |
| Manual Pulse Feed (per Rev of Handwheel) | 0.001"/0.01"/0.05" |
| Hand Feed per Revolution | 0.05" |
| Graduation of Handwheel (X0.1/X1/X5) | 0.001"/0.01"/0.05" |
| Spark Outs | 0 - 5 |
| Rapid Feed (50 / 60 Hz) | 23.6 ipm |
| Wheel Diameter | 12" |
| Wheel Width | 1.5" |
| Wheel Bore Diameter | 5" |
| Foot Print | 111"L x 78"W x 73"H |
| Weight | 6,400 Lbs |
